ShaderTexZoom

Can be also used as a texture render pass, for two textures.

ShaderTexZoom Node

Scale and Reposition Textures

ShaderTexZoom provides independent control over texture scaling and positioning for both source (input region) and destination (output region). Use it to zoom into texture regions, reposition content, crop textures, or create picture-in-picture effects. Supports processing two textures simultaneously.

Reference

The following properties can be configured for this node:

Property Type Description
src scale - source x and y scale
src pos - source x and y position
dest scale - dest x and y scale
dest pos - dest x and y position
interpolate - use interpolation on output texture
texture one - use this node as texture render pass
texture two - use this node as texture render pass
Inlet Type Description
properties properties properties | use message [set <propertyPath> <value(s)>] (without node/<nodeName> at the beginning) to set internal properties
texture texture texture one (also used for texture fx)
texture texture texture two
Outlet Type Description
texture texture texture one altered
texture texture texture two altered

Source vs Destination

Understanding Scale and Position

ShaderTexZoom uses a source-to-destination mapping model:

Property Controls Effect
src scale Input region size Which portion of the source texture is sampled
src pos Input region position Where in the source texture to sample from
dest scale Output region size How large the result appears in the output
dest pos Output region position Where the result is placed in the output

Think of it as: "Take this region from the source (src) and place it here in the output (dest)."

Zoom and Pan Effects

Zooming Into a Texture Region

To zoom into a specific area of a texture:

  1. Connect your texture to the first texture inlet
  2. Set src scale to less than 1.0 (e.g., 0.5, 0.5) to select a smaller region
  3. Adjust src pos to center on the area of interest
  4. Set dest scale to 1.0 to fill the output
  5. Enable interpolate for smooth scaling

Result: The selected region is enlarged to fill the output.

Picture-in-Picture

To create a small inset of one texture:

  1. Connect your texture to the first inlet
  2. Keep src scale at 1.0 (use full source)
  3. Set dest scale to a smaller value (e.g., 0.25, 0.25)
  4. Set dest pos to position the inset (e.g., corner placement)

Result: The full texture appears as a small inset at the specified position.

Dual Texture Processing

Processing Two Textures

ShaderTexZoom can apply the same zoom/pan transformation to two textures simultaneously:

  • Connect textures to both texture inlets
  • Enable texture one and/or texture two to include them in the render pass
  • Both outlets provide the transformed versions

This is useful when you need to apply identical spatial transformations to related texture pairs (e.g., color and depth, left and right stereo).

Interpolation

Smooth vs Sharp Scaling

The interpolate property controls texture filtering:

Setting Effect
On Smooth, bilinear filtering (better for photographic content)
Off Nearest-neighbor, sharp pixels (better for pixel art or when preserving hard edges)

Enable interpolation when scaling up to avoid blocky artifacts.

Texture Render Pass Mode

Using as a Render Pass

Enable texture one or texture two to use ShaderTexZoom as part of a texture render pass:

  • The node will process textures during the render pipeline
  • Useful for integrating zoom effects into complex texture processing chains
  • Ensure proper render pass ordering if source textures come from other render operations
